rc.base.models

Abstract and concrete base classes for RomCom Models.

Properties

MetaData	Type for passing metadata as **kwargs.
Matrix	Types which a DataBase Table accepts.

Classes

Store	Base class for any stored class. Users are not expected to subclass this class directly.
Meta	Concrete class encapsulating metadata stored in a .json file.
Table	Concrete class encapsulating a pd.DataFrame backed by a .csv file.
DataBase	NamedTables(NamedTuple) in a folder alongside Meta. Abstract base class for any model.

Module Contents

MetaData

Type for passing metadata as **kwargs.

Matrix

Types which a DataBase Table accepts.

class Store(path)

Bases: rc.base.definitions.ABC

Base class for any stored class. Users are not expected to subclass this class directly.

Parameters:

path (rc.base.definitions.Path)

Path

Class attribute aliasing Types used to specify the path to a Store. Do not override.

ext: str = ''

Class attribute specifying the file extension terminating self.path. Override if and only if the derived class must be stored in a file. Otherwise, cls.ext == '' and the derived class is stored in a folder.

property path: rc.base.definitions.Path

The Path to this Store, without cls.ext. File extension is internal, meaning self._path = self._path + cls.ext.

Return type:

rc.base.definitions.Path

__repr__()

The Path to this Store.

Return type:

str

__str__()

The Path to this Store, abbreviated.

Return type:

str

abstractmethod __call__(**data)

Update and store self.

Parameters:

**data – Data to update.

Return type:

rc.base.definitions.Self

Returns: self.

classmethod extAppend(path)

Append cls.ext to path.name.

Parameters:

path (rc.base.definitions.Path) – The path to append cls.ext to.

Return type:

rc.base.definitions.Path

Returns: Path(path) with cls.ext appended.

classmethod mkdir(path)

Create path.parent, with a subfolder path if cls.ext == ''.

Parameters:

path (rc.base.definitions.Path) – The folder to create, or a child file of the folder to create.

Return type:

rc.base.definitions.Path

Returns: Path(path) with cls.ext appended.

classmethod create(path)

Abstractmethod:

Parameters:

path (rc.base.definitions.Path)

Return type:

rc.base.definitions.Self | rc.base.definitions.Path

Create a folder (and its parents) if it doesn’t already exist.

Overrides should create and return an instance of cls.

Parameters:

path (rc.base.definitions.Path) – Where to create the folder. If cls.ext != '', the parent folder of path is created.

Returns:

path with extension f'.{cls.ext}'.

Raises:

FileExistsError – If attempting to overwrite a file with a folder.

Return type:

rc.base.definitions.Self | rc.base.definitions.Path

classmethod copy(src, dst)

Abstractmethod:

Parameters:

• src (rc.base.definitions.Path)

• dst (rc.base.definitions.Path)

Return type:

rc.base.definitions.Self | rc.base.definitions.Path

Copy src to dst, overwriting only files in common.

Overrides should copy an instance of cls called src to Store.create(dst), and return the copy.

Parameters:

• src (rc.base.definitions.Path) – The source Path, which must be a folder or a file.

• dst (rc.base.definitions.Path) – The destination Path, which may or may not exist.

Return type:

rc.base.definitions.Self | rc.base.definitions.Path

Returns: dst.

Raises:

• FileNotFoundError – If src does not exist.

• FileExistsError – If attempting to overwrite a file with a folder.

Parameters:

• src (rc.base.definitions.Path)

• dst (rc.base.definitions.Path)

Return type:

rc.base.definitions.Self | rc.base.definitions.Path

classmethod delete(path)

Delete any file or folder at path.

Parameters:

path (rc.base.definitions.Path) – The Path to delete.

Return type:

rc.base.definitions.Path

Returns: path, which no longer exists.

class Meta(path, **data)

Bases: Store, dict

Concrete class encapsulating metadata stored in a .json file.

Parameters:

• path (Store)

• data (rc.base.definitions.Any)

ext: str = '.json'

Class attribute specifying the file extension terminating self.path. Override if and only if the derived class must be stored in a file. Otherwise, cls.ext == '' and the derived class is stored in a folder.

__call__(**data)

Update and store self, overwriting.

Parameters:

**data (rc.base.definitions.Any) – Data to update self.data.

Return type:

rc.base.definitions.Self

Returns: self.

__setitem__(key, value)

Indexer sets the value indexed by key.

classmethod create(path, **data)

Create a Meta at path, overwriting.

Parameters:

• path (Store) – The Path (file) to store self, overwritten if existing. A .json extension is automatically appended.

• **data (rc.base.definitions.Any) – The MetaData to store.

Returns: The Meta created.

classmethod copy(src, dst)

Copy src to dst, overwriting.

Parameters:

• src (Meta) – The source Meta.

• dst (Store) – The destination Path, overwritten if existing. A .json extension is automatically appended.

Return type:

rc.base.definitions.Self

Returns: The Meta now stored at dst.json.

class Table(path, data=None, **options)

Bases: Store

Concrete class encapsulating a pd.DataFrame backed by a .csv file.

This class may be usefully overridden to provide bespoke read and write options for file operations. Subclasses should follow the template (copy and paste it):

class MyTable(Table):

class Options(NamedTuple):

    read: MetaData =  {'index_col': 0}  #: Read options passed to ``pd.read_csv``.
    write: MetaData =  {}   #: Write options passed to ``pd.DataFrame.to_csv``.

    @classmethod
    def default(cls) -> MetaData:
        """ Returns the default Options as ``cls.read | cls.write``."""
        return cls._field_defaults['read'] | cls._field_defaults['write']

Parameters:

• path (Store)

• data (rc.base.definitions.Self | rc.base.definitions.Pd.DataFrame | None)

• options (rc.base.definitions.Any)

ext: str = '.csv'

Class attribute specifying the file extension terminating self.path. Override if and only if the derived class must be stored in a file. Otherwise, cls.ext == '' and the derived class is stored in a folder.

writeOptions: list[str] = ['sep', 'na_rep', 'float_format']

Class attribute listing kwargs which will be interpreted as write options. All other kwargs are interpreted as read options. To specify a separator, use delimiter as read option and sep as write option.

property options: MetaData

A dict of options for file operations involving ``self. Any option not in Table.writeOptions is stored in self.options.read and passed to pd.read_csv. Any option in Table.writeOptions is stored in self.options.write and passed to pd.DataFrame.to_csv. The setter updates via logical or |=, so existing values are retained unless explicitly updated.

Return type:

MetaData

property pd: rc.base.definitions.Pd.DataFrame

The Pd.DataFrame stored in self.

Return type:

rc.base.definitions.Pd.DataFrame

property np: rc.base.definitions.Np.Matrix

The Np.Matrix stored in self.

Return type:

rc.base.definitions.Np.Matrix

property tc: rc.base.definitions.Tc.Matrix

The TF.Matrix stored in self.

Return type:

rc.base.definitions.Tc.Matrix

broadcast_to(target_shape, is_diagonal=True)

Broadcast self.

Parameters:

• target_shape (rc.base.definitions.Tuple[int, int]) – The shape to broadcast to.

• is_diagonal (bool) – Whether to zero the off-diagonal elements of a square matrix.

Return type:

rc.base.definitions.Self

Returns: self.

Raises:

IndexError – If broadcasting is impossible.

Parameters:

• target_shape (rc.base.definitions.Tuple[int, int])

• is_diagonal (bool)

Return type:

rc.base.definitions.Self

__call__(data, **options)

Update and store self, overwriting.

Parameters:

• data (rc.base.definitions.Self | Matrix | None) – The data updates.

• **options (rc.base.definitions.Any) – Updates self.options, before storing self.

Return type:

rc.base.definitions.Self

Returns: self.

classmethod create(path, data=None, index=None, columns=None, dtype=None, copy=None, **metadata)

Create a Table at path, overwriting.

Parameters:

• path (Store) – The Path to store this DataTable, overwritten if existing. A .csv extension is automatically appended.

• data (rc.base.definitions.Self | Matrix | None) – The data to store. If None, a Pd.DataFrame is read from .csv. See pd.DataFrame.

• index (rc.base.definitions.Pd.Index | rc.base.definitions.Np.Array) –

  See pd.DataFrame.

• columns (rc.base.definitions.Pd.Index | rc.base.definitions.Np.Array) –

  See pd.DataFrame.

• dtype (rc.base.definitions.Np.DType | None) –

  See pd.DataFrame.

• copy (bool | None) –

  See pd.DataFrame.

• **metadata – MetaData passed to pd.read_csv or pd.DataFrame.to_csv.

Return type:

rc.base.definitions.Self

Returns: The DataTable created.

classmethod copy(src, dst)

Copy src to dst, overwriting.

Parameters:

• src (rc.base.definitions.Self) – The source DataTable.

• dst (Store) – The destination Path, overwritten if existing. A .csv extension is automatically appended.

Return type:

rc.base.definitions.Self

Returns: The DataTable now stored at dst.csv.

class DataBase(path, **tables)

Bases: Store

NamedTables(NamedTuple) in a folder alongside Meta. Abstract base class for any model.

DataBase subclasses must be implemented according to the template (copy and paste it):

class MyDataBase(DataBase):

    class NT(NamedTuple):

        names[i]: Table | Matrix | MetaData = pd.DataFrame(defaults[names[i]].pd)   #: Comment
        ...

        def __call__(self, name: str) -> Table | Matrix | MetaData:
            """ Returns the Table named ``name``."""
            return getattr(self, name)


    options: NamedTables[MetaData] = NamedTables(**{name: table.options for name, table in {}.items()})
    """ Class attribute of the form ``NamedTables(**{names[i]: options[i], ...})``.
    Override as necessary for bespoke ``Table.options``.
    Elements of ``options[i]`` found in ``Table.writeOptions`` populate ``self[i].options.write``,
    the remainder populate ``self[i].options.read``."""

    defaultMetaData: MetaData = {'Tables': Tables.options._asdict()}

Parameters:

• path (Store)

• tables (Table | rc.base.definitions.Pd.DataFrame)

class NamedTables

Bases: rc.base.definitions.NamedTuple

Must be overridden.

__call__(name)

Returns the Table named name.

Parameters:

name (str)

Return type:

Table | Matrix | MetaData

options: NamedTables[MetaData]

Class attribute of the form NamedTables(**{names[i]: options[i], ...}). Override as necessary for bespoke Table.options. Elements of options[i] found in Table.writeOptions populate self[i].options.write, the remainder populate self[i].options.read.

property nt: NamedTables

The NamedTables currently in self.

Return type:

NamedTables

property meta: Meta

The Meta currently in self.

Return type:

Meta

__len__()

Counts the Table s in self.

Return type:

int

__getitem__(name)

Indexer returns the Table (s) named or sliced by name.

Parameters:

name (str | slice)

Return type:

Table | rc.base.definitions.Tuple[Table, Ellipsis]

__setitem__(name, tables)

Indexer sets the Table (s) named or sliced by name.

Parameters:

• name (str | slice)

• tables (Table | Matrix | rc.base.definitions.Tuple[Table | Matrix, Ellipsis])

__call__(**tables)

Update and store self, overwriting.

Parameters:

• path – Optionally, an update to self.path, overwritten if existing.

• **tables (Table | Matrix) – Updates to self in the form names[i]=Table[i], ....

Return type:

rc.base.definitions.Self

Returns: self.

classmethod names()

(names[i], ...) of table names for this Tables class.

Return type:

rc.base.definitions.Tuple[str, Ellipsis]

classmethod defaults()

{names[i]: Pd.DataFrame[i], ...} of default tables for this Tables class.

Return type:

rc.base.definitions.Dict[str, rc.base.definitions.Pd.DataFrame]

classmethod create(path, **tables_and_meta)

Create a DataBase in path.

Parameters:

• path (Store) – The folder to store the DataBase in. Need not exist, any existing Tables will be overwritten if it does.

• **tables_and_meta (Table | rc.base.definitions.Pd.DataFrame | MetaData) – Data to update cls.defaults(), in the form names[i]=tables[i], and optional MetaData to update cls.defaultMetaData in the form meta=MetaData.

Return type:

rc.base.definitions.Self

Returns: The DataBase created.

classmethod copy(src, dst)

Copy src to dst, overwriting any files in common.

Parameters:

• src (rc.base.definitions.Self) – The source DataBase.

• dst (Store) – The destination Path, which may or may not exist.

Return type:

rc.base.definitions.Self

Returns: The DataBase now stored in dst.

classmethod delete(path)

Delete all DataBase files in path, retaining path and any other files it contains.

If you wish to delete path entirely, use Store.delete(path) instead.

Parameters:

path (Store) – Path to the DataBase to delete.

Return type:

rc.base.definitions.Path

Returns: path, which still exists.
